Fluke 190-504 ScopeMeter Repair
The Fluke 190-504 is a 500 MHz four-channel handheld ScopeMeter (190 Series II), the flagship of the line, with fully isolated inputs for demanding troubleshooting. With fully isolated inputs for safe floating measurements, its faults concentrate in the isolated input front-ends, the display, and the battery/power section.
FlukeServiceCenter.com repairs and calibrates the Fluke 190-504 for industrial electricians, automation technicians, and field-service engineers.
Common Fluke 190-504 problems we fix
- Waveform-capture / bus-health faults — the capture or bus-health test returning wrong results, repaired.
- Input-channel restoration — a dead, noisy, or inaccurate channel from front-end damage, repaired and recalibrated.
- Isolated-input breakdown — damage to the floating input isolation, repaired.
- Display failure — blank, dim, or cracked display, repaired.
- Won’t power on or hold a charge — battery and power faults, serviced.
FAQs
A channel on my 190-504 is off — fixable? Yes. Isolated-input and trigger faults are repairable, then each of the four channels is recalibrated so measurements are accurate, with a NIST-traceable certificate.
Are the inputs recalibrated? Yes — each of the four channels is checked against our standards.
Every repair includes NIST-traceable calibration and a 90-day parts-and-labor warranty. Email us or request service.
Duaine White –
Our Fluke scopemeter would not take a charge, therefore died, but the battery was good. Checked everything I could and ended up sending in for evaluation. They gave me a detailed explanation of the repair and did a great job repairing and certifying the scopemeter.
